In the production process of NC blades, drill bits, milling cutters and other round edge tools, it is necessary to measure the edge with a tool measuring instrument to provide quality assurance. So, in this regard, what are the advantages and functions of the vertical and horizontal dual lens tool measuring instrument? Today, Guangdong Weimi will come with you to see the superior performance of vertical and horizontal double lens tool measuring instrument WEIMI212T.

The vertical and horizontal dual lens tool measuring instrument WEIMI212T is equipped with two high-definition CCD cameras and adopts full-automatic zoom technology. It can more conveniently observe and measure the measured tool from the blade and straight face without moving the tool, and automatically realize the multi blade measurement of the tool, so as to reduce the error of human operation. It is an ideal tool for measuring complex tools.

The tool measuring instrument adopts coaxial high-precision rotating fixture in double lens, which greatly facilitates the measurement. The user only needs one clamping to realize the measurement of multiple axes such as X, y and Z axes, horizontal lens rotation axis and tool rotation, so as to avoid the error caused by multiple clamping, which is an advantage that other ordinary measuring instruments do not have.

The vertical and horizontal dual lens tool measuring instrument WEIMI212T can accurately measure the diameter, length, cutting edge spacing, front angle, back angle, spiral angle, main deflection angle, auxiliary deflection angle and other dimensions of the tool. The user can not only measure the edge parameters of multiple different positions of the tool, but also analyze the structure and roughness of the specified position of the tool, so as to detect the tool quality Or compare the preparation process of the cutting edge.

Due to its outstanding performance advantages and convenient use, the vertical and horizontal dual lens tool measuring instrument is favored by manufacturers of drilling tools, milling tools, or extremely complex cutting tools, as well as manufacturers of cutting tool steel or fine grinding.
